Length: 2m or 3m or 4m
Width: 2.1m
Height: 2.1m
All flat packed units are 300mm high
All assembled units are 2093mm high
It is also possible to order bespoke sizes.
| Type | Length | Width | Weight |
|---|---|---|---|
| 2m Model | 2081mm | 2149mm | 296kg |
| 3m Model | 3064mm | 2149mm | 374kg |
| 4m Model | 4064mm | 2149mm | 454kg |
Expandastore is an uninsulated, closed-volume, demountable storage container.
Assembly of the store is simple, using nuts and bolts supplied.
| Feature | ES2 | ES2PC | ES3 | ES3PC | ES4 | ES4PC |
|---|---|---|---|---|---|---|
| Finish | Galvanised | Powder Coated | Galvanised | Powder Coated | Galvanised | Powder Coated |
| Length (mm) | 2081 | 2081 | 3064 | 3064 | 4064 | 4064 |
| Width (mm) | 2149 | 2149 | 2149 | 2149 | 2149 | 2149 |
| Height, flat packed (mm) | 300 | 300 | 300 | 300 | 300 | 300 |
| Height, assembled (mm) | 2093 | 2093 | 2093 | 2093 | 2093 | 2093 |
| Weight (kg) | 296 | 296 | 374 | 374 | 454 | 454 |
| Door width (mm) | 1250 | 1250 | 1250 | 1250 | 1250 | 1250 |
The main construction elements of the man-portable building are as follows:
| Component | 2M UNIT | 3M UNIT | 4M UNIT |
|---|---|---|---|
| Chassis | 88kg | 120kg | 153kg |
| Side Panel | 31kg | 45kg | 60kg |
| End Panel | 31kg | 31kg | 31kg |
| Door Panel | 67kg | 67kg | 67kg |
| Roof Panel | 48kg | 66kg | 83kg |
Pre-fitted 18mm grade 3 ‘Norbord’ Canadian Sterling Board screwed to a galvanised steel profile frame.
Box profile galvanised steel.
0.6 mm box profile galvanized steel panels. The panels have been strengthened and galvanized steel frame sections at the edges of each panel. The roof section has two integral gutters for effective rainwater dispersal to all four corners of the container.
0.6 mm box profile galvanized steel panel. The door is mounted into the frame with stainless steel hinges. Complete with two 64mm Euro deadlocks with replaceable cylinders and a central roller catch. Door width: 1250mm, hinged on the right, outward opening.
Four 12 mm diameter rods are used to connect the roof to the chassis. These also form lifting eyes for use with a crane. Additional roof security bolts are supplied to prevent external access to the man-portable building.
All components of the Expandastore man-portable building are specially packed to ensure that they are not damaged during transportation, loading and unloading under normal circumstances. The smallest transportation cube is achieved in this packing process.
Optional powder coating in green (RAL 6005), blue (RAL 5010) and Anthracite Grey (RAL 7016). Other colours from the standard RAL range are available upon request.
Doors fitted in the long side are a no-cost option.
Prices vary depending on building specification requirements and delivery/installation logistics, so please call 01342 830040 to discuss your individual requirements.
Note: Due to our continuous product development programme, we reserve the right to change the specifications without prior notice.
